Cape Peron to Albany

Cape Peron to Albany

1083 - Albany



Scale: Side A : 25000
Side B : various

Edition: 2
Chart number: WA 1083
Horizontal datum relates to: GDA94

A Low resolution chart for Albany side AB Low resolution chart for Albany side B



Notices for mariners - Albany


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
18 22/02/2019 Insert
(front)
Anchorage berths with 560 metre swing radii in positions
W   35° 04.70' S   117° 59.40' E
X   35° 02.00' S   118° 00.00' E
Y   35° 03.60' S   118° 01.00' E
Z   35° 04.40' S   117° 57.40' E
Delete
(front and Albany Inner Harbour Inset)
Major light and text   FR   in position
35° 02.10' S   117° 53.74' E
17 23/02/2018 Amend
(Albany Inner Harbour Inset)
Light character from   Fl G 4.5s   to   Fl G 3s   in position
35° 01.94' S   117° 53.27' E
Light character from   Fl R 4.5s   to   Fl R 3s   in position
35° 01.98' S   117° 53.32' E
Insert
(Oyster Harbour Inset)
Unlit port beacon with top mark in position
34° 56.42' S   117° 58.56' E
Starboard top mark to unlit beacon in position
34° 57.29' S   117° 58.51' E
16 03/07/2017 Advise
(front)
Changes to depths at Gio Batta Patch in King Sound.
Download this block insert for Albany NTM 16 as a PDF file that can be printed without scaling and pasted onto your paper chart.
Delete
(Oyster Harbour Inset)
Unlit pile in position
34° 59.30' S   117° 58.34' E
15 25/01/2017 Remove
(Oyster Harbour and Emu Point Boat Harbour Insets)
Top mark from lit red port buoy in position
34° 59.26' S   117° 56.85' E
Substitute
(Front and Oyster Harbour and Emu Point Boat Harbour Insets)
Unlit starboard beacon with lit starboard beacon, top mark and text   Fl G 3s 3M   in position
34° 59.59' S   117° 56.73' E
14 20/12/2016 Advise
(Oyster Harbour Inset)
The aquaculture lease boundaries and navigation aids have changed.
Download this block insert for Albany NTM 14 as a PDF file that can be printed without scaling and pasted onto your paper chart.
Substitute
(Emu Point Boat Harbour Inset)
Unlit starboard beacon 3A with lit starboard beacon, top mark and text   Fl G 3s 3M   in position
34° 59.44' S   117° 57.06' E
13 21/07/2016 Delete
(front)
Lit wreck with text   Fl Y 5s 2M   in position
35° 04.79' S   115° 58.08' E
The identification of the Perth wreck has changed.
Insert
Submerged wreck and lit yellow spar buoy with text   Fl(4) Y 10s 2M   in position
35° 04.79' S   115° 58.08' E
12 06/07/2016 Delete
(Albany Inner Harbour Inset)
Depth text   1.4   in position
35° 02.33' S   117° 54.68' E
Insert
Depth text   0.7   in position
35° 02.33' S   117° 54.67' E
Depth text   1.1   enclosed by contour in position
35° 02.19' S   117° 54.81' E
Amend
(front)
Aquaculture area boundary has changed in position
35° 03.93' S   117° 56.65' E
11 15/06/2016 Insert
(front)
Depth text   14.9   enclosed by contour in position
35° 01.69' S   117° 57.33' E
10 27/05/2016 Insert
(front)
Lit west cardinal pillar buoy with top mark and text   VQ(9) 10s 5.1m 4.6M   in position
35° 02.88' S   117° 59.53' E
9 19/04/2016 Insert
(Emu Point Boat Harbour Inset)
Sounding with value of   0.8   in position
34° 59.45' S   117° 57.06' E
8 04/11/2015 Advise
(front)
Shoaling has occurred in King George Sound.
Download this block insert for Albany NTM 8 as a PDF file that can be printed without scaling and pasted onto your paper chart.
7 18/08/2015 Substitute
(Main and Inner Harbour Inset)
Lit green spar buoy, with lit green starboard pillar buoy and top mark in position
35° 02.39' S   117° 54.63' E
The light character is unchanged - Fl G 1.5s 2M
6 02/06/2015 Remove
(Oyster Harbour Inset)
Overhead power line information at Lower Kalgan Bridge and Lower King Bridge. The overhead conductors have been replaced with underground cables.
5 07/05/2015 Substitute
(Oyster Harbour Inset)
Unlit beacon with lit north cardinal beacon, top mark and text   Q 2M   in position
34° 59.31' S   117° 57.92' E
4 25/02/2015 Insert
(front)
Breaksea Island light characters to   Fl(2) 6s 119m 13M & Oc R 1.5s 119m 15M   in position
35° 03.87' S   118° 03.31' E
Text to read   White Obscured   in position
36° 06.66' S   118° 00.84' E
Insert
(Breaksea Island Light - front)
Light sector between 020·0° - 043·5° with text   Red Arc of Visibility
Light sector between 036·0° - 040·5° south of Bald Head with text   Red Obscured
Light sector between 040·5° - 043·5° south of Bald Head with text   Red Arc of Visibility
3 04/12/2014 Substitute
(front and Emu Point Inset)
Unlit starboard beacon with lit starboard spar buoy, without top mark and light character   Fl G 3s 2.5M   in position
35° 00.03' S   117° 56.92' E   and
Unlit starboard beacon with lit starboard beacon, top mark and light character   Fl G 3s 2.5M   in position
34° 59.94' S   117° 56.99' E
2 29/05/2014 Advise
(Oyster Harbour Inset)
Aquaculture site established and water ski boundary adjusted.
Download this block insert for Albany NTM 2 as a PDF file that can be printed without scaling and pasted onto your paper chart.
1 03/04/2017 Insert
(front)
Lit yellow spar buoys without top marks and text   Fl Y 5s   in positions
35° 01.29' S   117° 55.30' E
35° 05.21' S   117° 56.76' E

1681 - Augusta



Scale: Side A : 25000
Side B : various

Edition: 1
Chart number: WA 1681
Horizontal datum relates to: GDA94

Download high resolution chart for Augusta


Notices for mariners - Augusta


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
6 05/09/2018 Advise
Submarine cable location amended near the shore in Flinders Bay.
Anchoring is prohibited within 100 metres either side of the submarine cable when inside Western Australian state waters.
Details are shown on the updated chart available as a free download.
5 20/08/2018 Advise
All fishing is restricted inside the Sanctuary Zones now established in the vicinity of Cape Leeuwin and Flinders Bay.
Details are shown on the updated chart available as a free download.
4 04/05/2018 Advise
Submarine Cable caution note added.
3 05/07/2017 Amend
Light character text to   Fl 7.5s 56m 25M   in position
34° 22.50' S   115° 08.03' E
2 26/06/2017 Delete
Aquaculture boundaries and associated text centred on
34° 21.72' S   115° 11.06' E
34° 21.69' S   115° 11.73' E
34° 22.45' S   115° 12.37' E
Insert
Magenta text   CAUTION Aquaculture see Note   in position
32° 22.35' S   115° 12.16' E
and enclosed by dashed magenta line between positions
34° 21.30' S   115° 11.48' E
34° 22.46' S   115° 12.78' E
34° 22.99' S   115° 12.11' E
34° 21.83' S   115° 10.82' E
1 17/02/2016 Delete
Unlit port mark in position
34° 19.34' S   115° 10.06' E
Unlit starboard mark in position
34° 19.31' S   115° 10.09' E

755 - Bouvard



Scale: Side A : 50000
Side B : various

Edition: 4
Chart number: WA 755
Horizontal datum relates to: GDA94

A Low resolution chart for Bouvard side AB Low resolution chart for Bouvard side B



Notices for mariners - Bouvard


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
14 24/12/2018 Insert
(front and reverse)
Lit starboard mark with top mark and text   Fl G 4s 2M   in positions
32° 37.04' S   115° 39.09' E
13 09/08/2018 Insert
(front)
Magenta swimming prohibited dashed line between positions
32° 35.98' S   115° 37.70' E   and
32° 35.98' S   115° 37.85' E
Magenta text   Swimming is prohibited within the Dawesville Channel   in position
32° 36.66' S   115° 38.22' E
Magenta text   CAUTION - 8 knots in the Harvey Channel   in position
32° 36.30' S   115° 40.57' E
Advise
(Dawesville Channel Inset)
Download this block insert for Bouvard NTM 13 as a PDF file that can be printed without scaling and pasted onto your paper chart.
12 28/06/2017 Advise
Changes have occurred to existing navigation aids, and new navigation aids have been installed in the Dawesville Channel and Harvey Estuary.
Download this block insert for Bouvard NTM 12 as a PDF file that can be printed without scaling and pasted onto your paper chart.
11 22/12/2016 Remove
(Dawesville Channel Inset)
Swimming Prohibited Area dashed magenta line and associated magenta text, and over-beach launching symbol and associated text, at Falcon Bay.
10 22/12/2016 Amend
(Front)
Starboard beacon navigation aid text to   Fl G 4s 7m 5M   in position
32° 35.98' S   115° 37.40' E
(Dawesville Channel Inset)
Port beacon navigation aid text to   Fl R 4s 8m 5M   in position
32° 35.98' S   115° 37.98' E
and starboard beacon navigation aid text to   Fl G 4s 7m 5M   in position
32° 35.98' S   115° 37.55' E
Insert
(Dawesville Channel Inset)
Lit port beacon with top mark and text   Fl R 4s 8m 5M   in position
32° 35.92' S   115° 37.84' E
9 09/02/2016 Substitute
(reverse)
Unlit port beacons with lit port beacons, top marks and text   Fl R 3s   in positions
32° 40.00' S   115° 39.31' E
32° 40.00' S   115° 39.37' E   and
Unlit starboard beacons with lit starboard beacons, top marks and text   Fl G 3s   in positions
32° 39.98' S   115° 39.33' E
32° 39.98' S   115° 39.39' E
8 12/05/2015 Advise
(front & reverse)
Waterway use regulations have changed in the Peel Inlet and Harvey Estuary.
Download this block insert for Bouvard NTM 8 as a PDF file that can be printed without scaling and pasted onto your paper chart.
Insert
(reverse)
Dashed magenta 5 knot speed restriction line between positions
32° 36.50' S   115° 45.00' E
32° 37.45' S   115° 45.00' E
32° 37.45' S   115° 43.42' E
32° 37.92' S   115° 43.42' E
Substitute
Text   4 knots   with text   5 Knots   in positions
32° 45.71' S   115° 42.46' E   (front)
32° 45.68' S   115° 42.66' E   (reverse)
32° 44.87' S   115° 42.22' E   (reverse)
7 08/05/2015 Insert
(front & reverse)
Minor lights with text   Fl R 4s   in positions
32° 36.13' S   115° 38.08' E
32° 36.24' S   115° 38.07' E
32° 36.57' S   115° 38.86' E   and
Minor lights with text   Fl G 4s   in positions
32° 36.13' S   115° 38.11' E
32° 36.23' S   115° 38.05' E
32° 36.59' S   115° 38.90' E
6 07/05/2015 Substitute
(front & reverse)
Unlit east cardinal beacons with lit east cardinal beacons, top marks and text   Q(3) 10s   in positions
32° 40.04' S   115° 39.44' E
32° 40.12' S   115° 39.46' E   and
Unlit port beacon with lit port beacon, top mark and text   Fl R 3s   in position
32° 41.02' S   115° 40.70' E
5 06/09/2012 Advise
All waters in the bay adjacent to the beach at the north east end of Castaway Canal North Port Wannanup in position
32° 35.08' S   115° 38.35' E
are regulated as   Closed Waters to Motorised Vessels.
4 20/12/2010 Advise
(front)
Additional navigation aids are installed in the navigable channel linking Harvey Estuary and Peel Inlet. Mariners are advised that all port and starboard beacons now display synchronised lights.
Download this block insert for Bouvard NTM 4 as a PDF file that can be printed without scaling and pasted onto your paper chart.
3 20/12/2010 Advise
(Dawesville Channel Inset)
Additional navigation aids are installed in the navigable channel linking Harvey Estuary and Peel Inlet. Mariners are advised that all port and starboard beacons now display synchronised lights.
Download this block insert for Bouvard NTM 3 as a PDF file that can be printed without scaling and pasted onto your paper chart.
2 20/12/2010 Advise
(reverse)
Mariners are advised that port and starboard beacons now display synchronised lights. The Water Ski and PWC Area is defined by unlit yellow buoys.
Download this block insert for Bouvard NTM 2 as a PDF file that can be printed without scaling and pasted onto your paper chart.
1 13/08/2009 Substitute
Unlit starboard beacon with lit starboard beacon and text   Fl G 3s 2M   in position
32° 37.55' S   115° 38.66' E   and
Unlit port beacon with lit port beacon and text   Fl R 3s 2M   in position
32° 37.56' S   115° 38.64' E

859 - Bunbury to Port Geographe



Scale: Side A : 50000
Side B : various

Edition: 3
Chart number: WA 859
Horizontal datum relates to: GDA94

Download high resolution chart for Bunbury to Port Geographe


Notices for mariners - Bunbury to Port Geographe


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
9 05/09/2018 Advise
All fishing is restricted inside the East Geographe Sanctuary Zone established within the waters of Geoagraphe Bay.
Details are shown on the updated chart available as a free download.
8 24/07/2018 Amend
(Title Block)
2015 Tidal Plane values adjusted for Bunbury
Download this block insert for Bunbury to Port Geographe NTM 8 as a PDF file that can be printed without scaling and pasted onto your paper chart.
7 17/07/2018 Delete
(front and Bunbury Harbour Inset)
Light and text   2F G   in position
33° 19. 25' S   115° 38.48' E   and
Light and text   2F R   in position
33° 19. 25' S   115° 38.50' E
6 01/05/2018 Insert
(Bunbury Harbour Inset)
Sounding text   4.3   within enclosed 5m and 10m contours in position
33° 16.70' S   115° 39.42' E
5 07/02/2018 Advise
(Bunbury Harbour Inset)
Bridge clearance values added. Minor changes made to topographic details along the Koombana Bay foreshore.
Download this block insert for Bunbury to Port Geographe NTM 5 as a PDF file that can be printed without scaling and pasted onto your paper chart.
4 08/02/2017 Insert
(Inset)
Lit starboard beacon with top mark and text   Iso G 3s   in position
33° 17.66' S   115° 38.93' E
3 24/01/2017 Move
(Main and Port Geographe Marina Inset)
Lit green starboard pillar buoy and text   Q G 5M   from position
33° 37.68' S   115° 23.32' E   to position
33° 37.63' S   115° 23.23' E
2 03/10/2016 Insert
(Port Geographe Marina Inset)
Magenta text note in position
33° 38.61' S   115° 22.78' E
CAUTION
During the winter and spring months, weed build-up may occur in the Marina entrance channel. Mariners are cautioned accordingly.
1 13/04/2016 Amend
Light character of special buoy from   Q Y   to   Fl Y 5s   in position
33° 19.57' S   115° 37.35' E

966 - Cape Naturaliste



Scale: Side A : 50000
Side B : various

Edition: 3
Chart number: WA 966
Horizontal datum relates to: GDA94

Download high resolution chart for Cape Naturaliste


Notices for mariners - Cape Naturaliste


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
19 05/09/2018 Advise
All fishing is restricted inside the Sanctuary Zones now established in the vicinity of Cape Naturaliste and Geographe Bay.
Details are shown on the updated chart available as a free download.
18 05/07/2017 Amend
Light character text to   Fl(2) 10s 123m 26M   in position
33° 32.22' S   115° 01.43' E
17 24/01/2017 Move
(Main and Port Geographe Marina Inset)
Lit green starboard pillar buoy and text   Q G 5M   from position
33° 37.68' S   115° 23.32' E   to position
33° 37.63' S   115° 23.23' E
16 20/10/2015 Insert
Minor light with text   F Bu 2M   in positions
33° 36.08' S   115° 06.35' E
33° 37.86' S   115° 08.94' E
33° 39.38' S   115° 15.38' E
15 02/06/2015 Substitute
Lit yellow spar buoy without top mark and text   Fl Y 5s,   with lit yellow beacon without top mark, and text   Fl Y 5s   in position
33° 38.31' S   115° 20.72' E
14 21/04/2015 Advise
Port Geographe Marina breakwater entrance and navigation aid upgrades.
Download this block insert for Cape Naturaliste NTM 14 as a PDF file that can be printed without scaling and pasted onto your paper chart.
13 11/12/2014 Insert
Lit yellow spar buoy without top mark, and text   Fl Y 4s 2M   in position
33° 39.28' S   115° 00.40' E
12 02/04/2014 Insert
Lit yellow spar buoys without top mark, and text   Fl Y 5s   in positions
33° 38.31' S   115° 20.72' E
33° 34.35' S   115° 05.59' E
11 06/05/2013 Insert
Fish Haven symbol with depth   (22)   and text   Dunsborough Reef (Artificial)   in position
33° 33.96' S   115° 09.98' E
10 24/04/2013 Insert
This notice is cancelled by NTM 11.
Danger circle with depth 22m and text   Dunsborough Reef (Artificial)   in position
33° 33.96' S   115° 09.98' E
9 13/09/2012 Amend
(Port Geographe Marina Inset)
Light character of starboard beacon to   Q G 3m 2M   in position
33° 37.897' S   115° 23.35' E
8 22/06/2012 Amend
Busselton Jetty light character to   Fl R 3s   in position
33° 37.74' S   115° 20.30' E
7 20/07/2011 Substitute
Unlit yellow spar buoys with lit yellow spar buoys without top mark, and text   Fl Y 3s   in positions
33° 38.20' S   115° 18.08' E
33° 37.83' S   115° 19.45' E
33° 37.46' S   115° 20.82' E
6 29/06/2011 Advise
Motorised vessels are prohibited at Meelup and Castle Bay. The areas are marked by yellow spar buoys.
Download this block insert for Cape Naturaliste NTM 6 as a PDF file that can be printed without scaling and pasted onto your paper chart.
5 22/04/2010 Move
Lit spar buoy and text from position
33° 37.52' S   115° 22.88' E   to position
33° 37.55' S   115° 22.79' E
4 18/01/2010 Advise
New reference area for chart AUS 116 is defined.
Download this block insert for Cape Naturaliste NTM 4 as a PDF file that can be printed without scaling and pasted onto your paper chart.
3 18/01/2010 Advise
Geographe Bay has revised the Navigable Waters Regulation Area boundaries. Unlit yellow spar buoys define the Water Ski Take-off Area within the Swimming Prohibited Area at Point Templar.
Download this block insert for Cape Naturaliste NTM 3 as a PDF file that can be printed without scaling and pasted onto your paper chart.
2 18/01/2010 Advise
Navigable Waters Regulation Area boundaries have been revised in Geographe Bay. Unlit yellow spar buoys are used to define these areas.
Reference box to chart AUS116 is removed.
Download this block insert for Cape Naturaliste NTM 2 as a PDF file that can be printed without scaling and pasted onto your paper chart.
1 18/01/2010 Delete
Unlit Yellow buoy and text   Fish Haven (21)   in position
33° 35.05' S   115° 10.14' E
Insert
Text   Artificial Reef   in same position

913 - Cape Peron to Dawesville



Scale: Side A : 50000
Side B : various

Edition: 7
Chart number: WA 913
Horizontal datum relates to: GDA94

A Low resolution chart for Cape Peron to Dawesville side AB Low resolution chart for Cape Peron to Dawesville side B



Notices for mariners - Cape Peron to Dawesville


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
12 24/12/2018 Insert
(front and reverse)
Lit starboard mark with top mark, and text   Fl G 4s 2M   in positions
32° 37.04' S   115° 39.09' E
Amend
(front and reverse)
Halls Head light range to   11M   in position
32° 31.59' S   115° 42.00' E
11 08/08/2018 Advise
(Mandurah to Dawesville Channel Inset)
Navigable waters regulations have changed in the Dawesville Channel and Peel Inlet.
Download this block insert for Cape Peron to Dawesville NTM 11 as a PDF file that can be printed without scaling and pasted onto your paper chart.
10 08/08/2018 Advise
(front)
Infrastructure detail added to chart.
Grain silos East Rockingham.
Tower (conspic) Golden Bay.
Details are shown on the updated chart available as a free download.
9 28/06/2017 Advise
Changes have been made to the light characteristics of numerous navigation aids in the Mandurah Estuary, the Peel Inlet and the Harvey estuary.
Download this block insert for Cape Peron to Dawesville NTM 9 as a PDF file that can be printed without scaling and pasted onto your paper chart.
8 27/02/2017 Insert
(front)
Magenta text   Marine Farm (see note)   enclosed by dashed magenta line between positions
32° 21.08' S   115° 42.94' E
32° 21.31' S   115° 43.17' E
32° 21.25' S   115° 43.26' E
32° 21.02' S   115° 43.04' E
Amend
CAUTION NOTES text box in position
32° 31.00' S   115° 27.50' E
to include magenta text
Marine Farms
Mariners are advised that floating and submerged hazards
exist in this area. Special Marks identify areas of operation.
7 25/01/2017 Amend
(Mandurah to Dawesville Channel Inset)
Yellow buoy light character text from   Fl Y   to   Iso Y   in positions
32° 32.67' S   115° 43.22' E
32° 32.72' S   115° 43.34' E
32° 32.80' S   115° 43.46' E
6 22/12/2016 Amend
(Mandurah to Dawesville Channel Inset)
Port beacon navigation aid text to   Fl R 4s 8m 5M   in positions
32° 35.90' S   115° 37.97' E
32° 35.98' S   115° 37.98' E
and starboard beacon navigation aid text to   Fl G 4s 7m 5M   in position
32° 35.98' S   115° 37.56' E
(Front)
Port beacon navigation aid text to   Fl R 4s 8m 5M   in position
32° 35.98' S   115° 38.10' E
and starboard beacon navigation aid text to   Fl G 4s 7m 5M   in position
32° 35.98' S   115° 37.40' E
Insert
(Front)
Lit port beacon with top mark and text   Fl R 4s 8m 5M   in position
32° 35.91' S   115° 37.84' E
5 27/07/2016 Delete
(front)
All four lit cardinal pillar buoys, their flash characters, and magenta text   Wave Energy Converter Site   in position
32° 15.04' S   115° 39.05' E
Insert
Foul ground with text   (21)   in position
32° 15.04' S   115° 39.05' E
4 08/07/2016 Insert
(front)
Fish haven with text   (20.7)   in position
32° 31.58' S   115° 35.03' E
3 16/06/2016 Advise
(front)
Depths have been changed along Five Fathom Bank.
Download this block insert for Cape Peron to Dawesville NTM 3 as a PDF file that can be printed without scaling and pasted onto your paper chart.
2 10/06/2016 Advise
(front and reverse)
Navigable waters regulation boundaries have changed in the Rockingham/Safety Bay area.
Download this block insert for Cape Peron to Dawesville NTM 2 as a PDF file that can be printed without scaling and pasted onto your paper chart.
1 05/05/2016 Delete
(front and reverse)
Magenta text   Aerial Freestyle Area   in position
32° 16.12' S   115° 43.81' E
Delete
(front and reverse)
Magenta line between positions
32° 16.31' S   115° 43.91' E
32° 16.23' S   115° 44.01' E
32° 16.20' S   115° 43.98' E

698 - Hardy Inlet



Scale: Side A : 15000
Side B : various

Edition: 3
Chart number: DMH 698
Horizontal datum relates to: AGD66

Download high resolution chart for Hardy Inlet


Notices for mariners - Hardy Inlet


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
4 28/02/2008 Advise
The ocean entrance to Hardy Inlet has moved approx. 1200m to the north east. This is a particularly dynamic piece of coastline and the entrance may continue to move. Mariners are advised accordingly.
3 29/11/2007 Amend
Unlit isolated danger beacon, with unlit port beacon and top mark in position
34° 19.02' S   115° 09.75' E
2 29/11/2007 Delete
Starboard beacon with top mark in position
34° 17.00' S   115° 10.96' E
1 29/11/2007 Insert
Unlit port beacon with top mark in positions
34° 16.19' S   115° 11.96' E
34° 19.32' S   115° 09.84' E
Unlit starboard beacon with top mark in position
34° 16.24' S   115° 12.03' E
34° 16.78' S   115° 11.87' E
34° 18.27' S   115° 09.76' E
Unlit spar buoy without top mark in position
34° 19.50' S   115° 10.00' E

337 - Wilson Inlet



Scale: Side A : 20000
Side B : various

Edition: 1
Chart number: DMH 337
Horizontal datum relates to: AGD66

Download high resolution chart for Wilson Inlet


Notices for mariners - Wilson Inlet


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
10 22/03/2016 Advise
Changes to Navigable Waters Regulations have occurred in the Wilson Inlet and surrounding rivers.
Download this block insert for Wilson Inlet NTM 10 as a PDF file that can be printed without scaling and pasted onto your paper chart.
9 22/03/2016 Amend
Magenta text from   Closed Waters All Vessels   to   Closed Waters Motorised Vessels   in position
35° 01.73' S   117° 20.12' E
8 22/03/2016 Insert
Lit yellow spar buoys without top marks, and text   Fl Y 3s   in positions
34° 59.50' S   117° 20.86' E
35° 00.14' S   117° 20.21' E
These buoys mark rock shallows.
7 30/07/2012 Advise
Denmark River entry channel navaids are lit and synchronised with 3 second flash interval.
Download this block insert for Wilson Inlet NTM 7 as a PDF file that can be printed without scaling and pasted onto your paper chart.
6 30/07/2012 Delete
Unlit beacon post in position
34° 59.19' S   117° 27.09' E
5 22/03/2012 Advise
Marine use boundaries are established in Ratcliffe Bay at Ocean Beach.
Download this block insert for Wilson Inlet NTM 5 as a PDF file that can be printed without scaling and pasted onto your paper chart.
4 01/04/2009 Substitute
This notice is cancelled by NTM 7.
Unlit port beacon, with lit port beacon with top mark and text   Fl R 3s   in position
34° 58.36' S   117° 22.23' E
3 18/05/2004 Insert
Lit isolated danger beacon and text   Fl(2) 6s 2M   in position
34° 59.95' S   117° 20.44' E
2 18/05/2004 Insert
Lit north cardinal beacon and text   Q 2M   in position
34° 59.37' S   117° 23.89' E
1 18/05/2004 Insert
Lit south cardinal beacon and text   Q(6)+LFl 15s 2M   in position
34° 59.24' S   117° 27.10' E

1046 - Nornalup Inlet



Scale: Side A : 15000
Side B : various

Edition: 2
Chart number: WA 1046
Horizontal datum relates to: GDA94

Download high resolution chart for Nornalup Inlet


Notices for mariners - Nornalup Inlet


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
6 15/08/2018 Delete
Unlit port beacon with top mark in position
35° 00.48' S   116° 42.39' E
Unlit starboard beacon with top mark in position
35° 00.47' S   116° 42.41' E
Substitute
Unlit port beacon with lit port beacon, top mark and text   Fl R 3s 3M   in position
34° 58.75' S   116° 43.46' E
5 30/05/2016 Delete
Unlit beacon without top mark in position
35° 01.37' S   116° 44.11' E
4 17/02/2015 Delete
Unlit spar buoy in position
35° 00.14' S   116° 46.25' E
3 16/04/2013 Advise
Marine use boundaries and navigation aids have changed on Nornalup and Walpole inlets.
Download this block insert for Nornalup Inlet NTM 3 as a PDF file that can be printed without scaling and pasted onto your paper chart.
2 22/03/2012 Advise
A water ski area has been established at Sealers Cove in the Nornalup Inlet.
Download this block insert for Nornalup Inlet NTM 2 as a PDF file that can be printed without scaling and pasted onto your paper chart.
1 20/07/2011 Insert
Lit isolated danger spar buoy without top mark, and text   Fl(2) 10s 2M   in position
35° 01.8' S   116° 44.57' E

019 - Peaceful Bay



Scale: Side A : 10000
Side B : various

Edition: 1
Chart number: DMH 019
Horizontal datum relates to: AGD66

Download high resolution chart for Peaceful Bay


Notices for mariners - Peaceful Bay


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
5 24/05/2010 Insert
Lit port spar buoy with top mark and text   Fl R 2M   in position
35° 02.62' S   116° 55.84' E
4 24/05/2010 Insert
Lit starboard spar buoy with top mark and text   Fl G 2M   in position
35° 02.57' S   116° 55.81' E
3 24/05/2010 Insert
Lit starboard spar buoy with top mark and text   Fl G 2M   in position
35° 02.54' S   116° 55.79' E
2 23/01/2009 Insert
Lit front lead with text   F B 10m 3M   in position
35° 02.49' S   116° 55.71' E
Lit rear lead with text   F B 15m 3   in position
35° 02.48' S   116° 55.70' E
Dashed lead line between positions
35° 02.48' S   116° 55.70' E
35° 03.32' S   116° 56.65' E
Bearing text   317·1°   along lead line in position
35° 03.27' S   116° 56.59' E
1 23/01/2009 Delete
Front lead in position
35° 02.49' S   116° 55.73' E
Rear lead in position
35° 02.47' S   116° 55.72' E
Delete associated lead line and bearing text.

848 - Peel Inlet and Harvey Estuary



Scale: Side A : 25000
Side B : various

Edition: 5
Chart number: WA 848
Horizontal datum relates to: GDA94

A Low resolution chart for Peel Inlet and Harvey Estuary side AB Low resolution chart for Peel Inlet and Harvey Estuary side B



Notices for mariners - Peel Inlet and Harvey Estuary


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
5 24/12/2018 Insert
(front and reverse)
Lit starboard mark with top mark, and text   Fl G 4s 2M   in positions
32° 37.04' S   115° 39.09' E
Amend
(front and reverse)
Halls Head light range to   11M   in position
32° 31.59' S   115° 42.00' E
4 22/08/2018 Substitute
(front)
Lit starboard beacon with lit green spar buoy without topmark in position
32° 34.36' S   115° 48.89' E
The light character is unchanged.
3 15/08/2018 Amend
(front Inset)
Light range from 3M to 5M for buoys at Mandurah Bridge in positions
32° 32.07' S   115° 43.03' E
32° 32.06' S   115° 43.06' E
32° 32.12' S   115° 43.05' E
32° 32.11' S   115° 43.08' E
2 10/08/2018 Advise
(front and Dawesville Channel Inset)
Speed restrictions and navigation aid amendments in the Dawesville and Harvey Channels.
Download this block insert for Peel Inlet and Harvey Estuary NTM 2 as a PDF file that can be printed without scaling and pasted onto your paper chart.
1 10/08/2018 Advise
(front and Inset)
New bridge and navigation aid changes in Mandurah.
Download this block insert for Peel Inlet and Harvey Estuary NTM 1 as a PDF file that can be printed without scaling and pasted onto your paper chart.

776 - Preston to Bunbury



Scale: Side A : 50000
Side B : various

Edition: 3
Chart number: WA 776
Horizontal datum relates to: GDA94

A Low resolution chart for Preston to Bunbury side AB Low resolution chart for Preston to Bunbury side B



Notices for mariners - Preston to Bunbury


A free PDF reader software (Acrobat Reader) may be downloaded from Adobe® to display map images presented
as links within the notice description.

Note: Transport is not responsible for external links and is unable to offer software or computer support.

External Link
Adobe - Acrobat Reader

Notice number Notice date Notice description
9 17/07/2018 Delete
(reverse)
Light and text   2F G   in position
33° 19. 25' S   115° 38.48' E   and
Light and text   2F R   in position
33° 19. 25' S   115° 38.50' E
8 01/06/2018 Substitute
(reverse)
Unlit starboard beacons with lit starboard beacons, top marks and text   Fl G 3s   in positions
33° 18.14' S   115° 41.22' E
33° 18.17' S   115° 41.36' E
33° 18.24' S   115° 41.48' E   and
Unlit port beacons with lit port beacons, top marks and text   Fl R 3s   in positions
33° 18.13' S   115° 41.24' E
33° 18.16' S   115° 41.38' E
33° 18.23' S   115° 41.50' E
7 01/05/2018 Substitute
(front and reverse)
Sounding text   8.6   with sounding text   4.3   within enclosed 5m contour in position
33° 16.70' S   115° 39.42' E
6 07/02/2018 Advise
(reverse)
Bridge clearance values added. Minor changes made to topographic details along the Koombana Bay foreshore.
Download this block insert for Preston to Bunbury NTM 6 as a PDF file that can be printed without scaling and pasted onto your paper chart.
5 08/02/2017 Insert
(front and reverse)
Lit starboard beacon with top mark and text   Iso G 3s   in position
33° 17.66' S   115° 38.93' E
4 31/03/2014 Insert
(reverse)
Lit yellow spar buoy without top mark, and text   Fl Y 5s   in position
33° 19.56' S   115° 37.36' E
3 12/03/2014 Advise
(front)
CAUTION - Desalination outfall information.
Download this block insert for Preston to Bunbury NTM 3 as a PDF file that can be printed without scaling and pasted onto your paper chart.
2 13/01/2014 Advise
(front)
Mariners are advised of changes to the 8 knot speed restriction areas, water ski areas, PWC areas and navigation aids in the Port of Bunbury.
Download this block insert for Preston to Bunbury NTM 2 as a PDF file that can be printed without scaling and pasted onto your paper chart.
1 24/04/2013 Insert
(front and reverse)
Fish Haven symbol with depth   (12.7)   and text   Bunbury Reef (Artificial)   in position
33° 18.50' S   115° 35.90' E



Page last updated: Tue Jul 5 2016 9:55:59 AM
